Today to introduce the industrial connector connection form, respectively, plug, cabinet, thread, bayonet four, as follows.
1, plug-in connection: plug-in connection is a multi-purpose connection form. Connector plugs and sockets connected or separated are not required to twist or rotate, its movement is a linear motion, so the working space does not require too much, you can complete the connection and separation. The plug and socket connection method has two structures: ball and pin. The connection method because there is no mechanical force-saving mechanism, so if the operation is wrong, it will feel the obvious increase of mechanical resistance and can be found in time.
2, the cabinet connection: This connection is suitable for some close to the frame, the need to blindly connect the electrical connectors on the equipment, can make the electrical equipment do very relatively light and small, easier to maintain. This form of connection the operator is not able to feel the connection, so a precise positioning device is needed to avoid the industrial electronic connectors are forced together incorrectly. The cabinet connection method usually uses floating or flexible contact design structure to ensure that its connection is correct.
3, threaded connection: often used in some of the larger size contact parts or in the strong vibration of the working environment between the original parts of the connection. This form of connection can be installed after the completion of the connection to prevent loosening of the fuse, more stable and reliable, but even the unloading speed is slow.
4, bayonet connector: this connector is a reliable and rapid form of connection and separation. Most bayonet connectors have a visual display of the correct connection and locking, which can be observed directly from the small hole in the side of the connector's connection nut, making it easier to install.
